SDI
The SDI Bus is a addressable bus mainly on some mainly on the newest Radionics and earliest Bosch panels which connects to system components, such as keypads, zone/output expanders, diagnostic tools, and wireless receivers. The SDI bus is still available on the Bosch G-Series (Bosch's newest flagship fire/intrusion panel) for backwards compatibility with older devices for use with retrofitting older 7000/9000 series panels.
Supervised and Unsupervised Keypads
Each panel supports a certain amount of supervised keypads depending on the panel. Each panel has a maximum amount of supervised keypads, if you set a keypad address to be unsupervised, you can have multiple keypads on that address. While the manuals list a max limit of unsupervised keypads, you can use an infinite amount of keypads on an unsupervised address if you have enough power/power supplies to do so.
List of SDI compatible panels
- B9512G
- B8512G
- D9412GV4
- D7412GV4
- D7212GV4
- D9412GV3
- D7412GV3
- D7212GV3
- D9412GV2
- D7412GV2
- D7212GV2
- D9412G
- D9124G
- D7412G
- D7212G
List of SDI compatible devices
Keypads (Command Centers)
Includes newer style B models mainly for GV2/GV3/GV4 panels
- D720 LED Keypads
- 1250 VFD Keypad Series
- D1255 Burg Keypad
- D1255R Fire Keypad
- D1256R Fire Keypad
- D1257R Fire Keypad
- Enhanced Command Center
- D1260 LCD Keypad
- D1265 Touch Screen Keypad
- Only compatible with GV2 panels and later
